| Observation Head |
Siedentopf Trinocular Head inclined 30˚ Rotatable 360˚, Interpupillary Distance 50 – 75 mm. |
| Focusing |
Co – axial coarse and Fine Focusing Knobs. |
| Mechanical Stage |
Large graduated mechanical stage with low drive co – axial controls for X–Y movements Stage Size 142 x 134 mm. Travel 76 x 50 mm. |
| Nosepiece |
Quadruple reversed mounted nosepiece. |
| Objectives |
Long working distance plan objectives : 5x, 10x, 45x & 100x Oil. |
| Eye Pieces |
Wide Field eye piece 10x – 18x mm. |
| Magnification |
50x to 1000x. |
| Illumination |
Epi – illumination 6V/20W Halogen Lamp (Reflection illumination System) & Transmitted LED 3W/Halogen 6V/20W (Optional). |
| Filters |
Blue, Ground Glass. |
