| Observation |
Monocular tube 45˚ rotatable through 360˚. |
| Magnification |
100x – 1000x. |
| Stand |
A rigid & heavy stand. |
| Focusing |
Coarse and fine focusing by conveniently placed separate knobs 1 div. 0.002 mm. |
| Stage |
Fixed square stage size 120 x 140 mm. with co-axial graduated Mechanical stage for X & Y movements up to 55mm to 75mm. |
| Illumination |
The illuminator incorporated 3W LED lamp and has adjustable brightness. |
| Condenser |
Sub stage Abbe filter holder N.A. 1.25 condenser with Iris diaphragm and swing out filter holder focusable by rack & pinion. |
| Nose Piece |
Triple revolving nose piece with positive click stops. |
| Objectives |
Achromatic 10x, 45x & 100x oil (SL). |
| Eye Pieces |
W.F. 10x Anti Fungus Coated. |
