| Observation Head |
Trinocular 45˚, 360˚ rotatable, with interpupillary and diopter adjustment. |
| Magnification |
100x to 1000x. |
| Mechanical Stage |
Co–axial low drive double plate mechanism system travel on ball bearing guide ways . |
| Illumination |
Built in base 6V – 20W Halogen lamp or LED 3W – 3V intensity control regulator. |
| Quadruple Nose Piece |
A precision mechanism ensures the accuracy and optical alignment of the system. |
| Sub stage Condenser |
Abbe type N.A. 1.25. with iris diaphragm for resolution and contrast control. |
| Phase Objectives |
10x, 20x (SL), 40x (SL) & 100x oil (SL) with centering telescope Eye piece & green filter. |
| Eye Pieces |
W.F. 10x paired with centering telescope eye piece & green filter. |
| USB Digital Camera |
5.0 Megapixel Color CMOS sensor, Size 1/2“, Pixel size 2.2×2.2 micron Resolution 2592×1944, PC interface, 30 bit color depth, exposure time 1 Microsecond to 2 seconds. High Image Transmission convenient to use any standard Microscope. Digital Camera can change image into Digital signal & send it to your P.C. |
