| Observation Head |
Trinocular, 1x magnification with interpupillary and diopter adjustment. |
| Magnification |
40x to 400x. |
| Stand |
Extra large size rectangular base, heavy & stable with transformer and electrical fitted in side. |
| Mechanical Stage |
Co–axial low drive, triple plate for comfortable and convenient manipulation of slide. |
| Focusing System |
Co–axial coarse & fine mechanism system with ball bearing guide ways. |
| Illumination |
Koehler’s illumination system 12V – 50W Halogen Lamp. |
| Quadruple Nose Piece |
A precision mechanism ensures the accuracy and optical alignment of the system. |
| LWD Objectives |
4x, 10x , 20x (SL) & 40x (SL). Anti fungal coated & infinity corrected. |
| Eye Pieces |
10x paired. Extra Wide Field, Anti fungal & Anti reflected. |
| USB Digital Camera |
5.0 Megapixel Color CMOS sensor, Size 1/2“, Pixel size 2.2×2.2 micron Resolution 2592×1944, PC interface, 30 bit color depth, exposure time 1 Microsecond to 2 seconds. High Image Transmission convenient to use any standard Microscope. Digital Camera can change image into Digital signal & send it to your P.C. |
