| Observation |
Trinocular 45˚, 360˚ rotatable, with interpupillary and diopter adjustment. |
| Magnification |
50x – 450x. |
| Stand |
A rigid & heavy stand. |
| Focusing System |
Coarse and fine focusing by conveniently placed separate knobs 1 div. 0.002 mm. |
| Stage |
Compact ball bearing center able rotating stage 140mm diameter , graduated with vernier , lock and two specimen clips. |
| Illumination |
Built – in base 6V – 20W Halogen light source with precentered light condenser. |
| Condenser |
Sub stage Abbe filter holder N.A. 1.25 condenser with Iris diaphragm and swing out filter holder focusable by rack & pinion. |
| Nose Piece |
Quadruple revolving nose piece with positive click stops. |
| Analyzer |
Equipped with a Bertrand lens, which can be swung in and out of the microscope tube for conoscopy observation. Compensator slot at 45˚ accommodating 1/4 & 1/2 wave length retarding plates. |
| Polarizer |
Polarizer rotating and graduated to 360 degree |
| Objectives |
Achromatic P5x, P10x, P45x (SL). |
| Eye pieces |
Wide field 10x . & Wide field 10x with cross. |
